Model	932-30
Engine Model	YUNNEI 4102
Rated Power	58KW
Rated Speed	2400r/min
Number of cylinders - inner diameter	4-102
Dimension	650018502700mm
Wheel Base	2240mm
Minimum ground clearance	250mm
The performance parameters
System Pressure	28Mpa
Weight	5000kg
Maximum speed	30km/h
Max Climb Capability	30°
Minimum turning radius	4000mm
Mining parameters
Maximum excavation depth	2000mm
Excavation unloading height	3100mm
Maximum excavation radius	3700mm
Bucket width	55mm
Bucket capacity	0.1m³
Maximum excavation height	4300mm
Maximum Digging Force	28KN
Rotary Angle of excavator	280°
Loading parameters
Maximum unloading height	3200mm
Maximum unloading distance	800mm
Bucket width	1800mm
Loading capacity	0.8M3
Maximum lift height for loading	4300mm
Maximum rising power	42KN
Shovel action time and	6.5s
Steering system type	Articulated full hydraulic steering
Steering Angle	33°
Tire	20.5-16
Front wheel air pressure	250-300kPa
Rear wheel air pressure	250-300kPa
Service brake	air top oil caliper disc brake
Parking brake	Air brake
Fuel tank/Hydraulic oil tank	63L/63L
Driving Type	4WD
