Self Loading Concrete Mixer Truck,wheel loader,dibo machinery

INQUIRY

Model	942-45
Engine Model	YUNNEI 4102 pressure
Rated Power	58KW
Rated Speed	2400r/min
Number of cylinders - inner diameter	4-102
Dimension	690019002800mm
Wheel Base	2550mm
Minimum ground clearance	250mm
The performance parameters
System Pressure	28Mpa
Weight	6500kg
Maximum speed	38km/h
Max Climb Capability	35°
Minimum turning radius	4250mm
Mining parameters
Maximum excavation depth	3000mm
Excavation unloading height	4100mm
Maximum excavation radius	4800mm
Bucket width	55mm
Bucket capacity	0.2m³
Maximum excavation height	5600mm
Maximum Digging Force	30KN
Rotary Angle of excavator	280°
Loading parameters
Maximum unloading height	3500mm
Maximum unloading distance	900mm
Bucket width	20 00mm
Loading capacity	1M3
Maximum lift height for loading	4700mm
Maximum rising power	90KN
Shovel action time and	6.8s
Steering system type	Articulated full hydraulic steering
Steering Angle	38°
Tire	16/70-20
Front wheel air pressure	300-350kPa
Rear wheel air pressure	300-350kPa
Service brake	air top oil caliper disc brake
Parking brake	Air brake
Fuel tank/Hydraulic oil tank	70L/70L
Driving Type	4WD
